Product Details:
|
| Input Voltage: | 24V | Protection Level: | IP66 |
|---|---|---|---|
| Warranty: | 5 Years | Application: | PV Solar Tracking System |
| Noise Level: | ≤50dB | Product Name: | Solar Tracker Slew Drive |
| Weight: | 23 Kg | Operating Temperature: | -40℃ To＋120℃ |
| Highlight: | RS485 Interface Solar Slew Drive,24V Solar Tracking Slew Drive,PV solar tracking Slew Drive |
||
Advanced Solar Tracking System With 3600ppr Resolution And RS485 Interface
Product Description
A slewing drive, also known as a slew drive or slew bearing drive, is a mechanical component used in various applications to enable the controlled rotation of a load around a central axis. These devices are commonly found in industrial machinery, solar tracking systems, wind turbines, construction equipment, and other applications where controlled and precise rotation is required.
Here is a description of key features and components of a slewing drive:
Main Housing: The slewing drive typically consists of a sturdy, compact housing that contains all the internal components. The housing is designed to withstand heavy loads and environmental conditions.
Central Axis: At the core of the slewing drive is a central axis, often referred to as the worm gear, which serves as the pivot point for the rotational movement.
Gear Mechanism: The primary function of the slewing drive is to convert rotary motion into angular motion. This is achieved through a gear mechanism, typically consisting of a worm screw and a ring gear. The worm screw engages with the teeth on the ring gear, allowing controlled rotation.
Drive Motor: To control the rotation of the slewing drive, an external drive motor is usually attached. The motor provides the necessary torque and power to rotate the load.
Bearings: High-quality bearings are crucial components of a slewing drive. They provide support and reduce friction, enabling smooth and efficient rotation. Some slewing drives feature multiple rows of bearings for enhanced stability.
Seals and Lubrication: To protect the internal components from dust, dirt, and moisture, slewing drives are equipped with seals and gaskets. Proper lubrication is essential to reduce wear and ensure long-term reliability.
Mounting Flange: Depending on the application, a mounting flange may be included to attach the slewing drive securely to the surrounding structure.
Output Gear: Some slewing drives have an output gear, which is connected to the load that needs to be rotated. This gear can be customized to suit the specific requirements of the application.
Slewing drives are designed to handle heavy loads and offer precise control over rotation, making them ideal for various applications that require controlled motion. Their versatility, durability, and ability to support both axial and radial loads make them valuable components in industries such as construction, renewable energy, and manufacturing.
Technical Parameters
Here is a brief description of the various models of reducer available:
|
Model |
Rated Output Torque (N.m) |
Holding Torque (kN.m) |
Tilting Torque (kN.m) |
Axial Load (kN) |
Radial Load (kN) |
Ratio |
Efficiency |
Precision (Degree) |
IP |
Working Tep(℃) |
Self-locking |
Weight (kg) |
|
3" |
806 |
9 |
5 |
22 |
15 |
31:1 |
40% |
≤0.15 |
66 |
-40～+80 |
Yes |
12kg |
|
5" |
962 |
30 |
6 |
16 |
27 |
37:1 |
40% |
≤0.15 |
66 |
-40～+80 |
Yes |
18kg |
|
7" |
7344 |
60 |
10 |
34 |
58 |
51:1 |
40% |
≤0.15 |
66 |
-40～+80 |
Yes |
32kg |
|
8" |
8000 |
70 |
14 |
50 |
80 |
50:1 |
40% |
≤0.15 |
66 |
-40～+80 |
Yes |
28kg |
|
9" |
8784 |
80 |
16 |
60 |
130 |
61:1 |
40% |
≤0.15 |
66 |
-40～+80 |
Yes |
52kg |
|
12" |
11232 |
100 |
25 |
77 |
190 |
78:1 |
40% |
≤0.15 |
66 |
-40～+80 |
Yes |
65kg |
|
14" |
12240 |
120 |
48 |
110 |
230 |
85:1 |
40% |
≤0.15 |
66 |
-40～+80 |
Yes |
88 kg |
|
17" |
14688 |
136 |
67 |
142 |
390 |
102:1 |
40% |
≤0.15 |
66 |
-40～+80 |
Yes |
135 kg |
|
21" |
18000 |
140 |
89 |
337 |
640 |
125:1 |
40% |
≤0.15 |
66 |
-40～+80 |
Yes |
192 kg |
|
25" |
21600 |
150 |
112 |
476 |
950 |
150:1 |
40% |
≤0.15 |
66 |
-40～+80 |
Yes |
251 kg |
Applications
Slewing drives are widely used in a variety of industries and applications where controlled rotation, precise positioning, and load-bearing capacity are essential for efficient operation. From solar tracking systems to wind turbines, construction equipment, and rotary tables, slewing drives enable the precise control of various components. They are also used in agricultural machinery, material handling equipment, marine and offshore equipment, aerial work platforms, renewable energy systems, satellite dishes, broadcasting systems, surveillance systems, automated manufacturing processes, defense and aerospace applications, amusement park rides, telescopes, and mining and quarrying equipment.
The versatility of slewing drives and their importance in a wide range of applications is unmatched. From energy generation to entertainment and defense to manufacturing, slewing drives enable efficient movement and precise positioning of various components, ensuring safe, efficient operation in a range of industries.
Support and Services
Solar Tracker Slew Drive Technical Support and Services
Our team of experienced engineers will help you identify issues and provide solutions for any problems you may encounter. We also provide a range of maintenance services, from regular preventive maintenance to emergency repairs and replacements.
We offer technical support and services for our customers, with a dedicated team of professionals who are always available to answer your queries and concerns. Our team is highly trained and knowledgeable in all aspects of Solar Tracker Slew Drive technology, and can provide you with the advice and expertise you need to keep your system running in top condition.
We also offer a range of customized services, including custom installation suggestion, and troubleshooting. Our team can work with you to identify any potential weak points in your system and provide tailored solutions to ensure optimal performance.
Our technical support and services are designed to give you the best possible experience with your Solar Tracker Slew Drive product. If you have any questions or concerns, please do not hesitate to contact us.
